Studer Compact XPC 2200-24
Product information "Studer Compact XPC 2200-24"
Studer Compact XPC 2200-24
The Compact series models consist of 3 fully automatic functions: a sine wave inverter, a battery charger and a transfer system. Equipped with high-end technology, they optimally perform, thanks to Studer Innotec's extensive experience in the field of electrical supply.
All Compact XPC series devices are also available in 120Vac/60Hz
Features and Performances
- True sine wave voltage
- Suitable for any kind of electrical appliance
- Reliable and silent working with all kind of loads
- Outstanding overload capabilities
- Stand-by level adjustable over a large range and from a very low threshold
- 4 STEP battery charger with PFC
- Ultra-fast transfer relay
- High efficiency
- Full internal protection
- Ultra-fast regulatio
- Microprocessor controlled
- 5 year warranty
The XPC 1400-12, XPC 2200-24, C 1600-12 and C 2600-24 are certified in accordance with the ECE-R 10 standard. This certification is mandatory in the European Union for all electrical equipment on board transport vehicles.
| Ausgangsfrequenz (Hz): | 50 |
|---|---|
| Ausgangsspannung (Vac): | 230 |
| Betriebstemperatur (°C): | -20° - +55° |
| Cos : | 0,1 - 1 |
| Dauerleistung bei 25°C (VA): | 1600 |
| Effiktiver Ladestrom, einstellbar (A): | 0 - 37 |
| Egalisierungsspannung (V): | 31,2 |
| Eigenverbrauch: OFF / Stand-By / ON (W): | 0,8 / 0,9 / 7 |
| Eingangsspannungsbereich AC (Vac): | 150 - 230 |
| Eingangsspannungsbereich DC (V): | 19 - 34 |
| Entladeschlussspannung (V): | 21,6 |
| Frequenzbereich (Hz): | 45 - 65 |
| Garantie (Jahre):: | 5 |
| Geräuschpegel, ohne /mit Lüfter (dB): | < 40 / < 45 |
| Gewicht (kg): | 12,6 |
| Ladeschlussspannung (V): | 28,8 |
| Lasterkennung (Stand-By) (W): | 1 - 25 |
| Leistung 5 Sek. bei 25°C (kVA): | 3 x Pnom |
| Leistung 30 Min. bei 25°C (VA): | 2200 |
| Länge / Breite (Tiefe) / Höhe (mm): | 410 / 124 / 215 |
| Max. Eingangsspannung DC (V): | 45 |
| Max. Eingangsstrom DC (A): | 30 |
| Max. Strom über Transfersystem (A): | 16 |
| Max. Wirkungsgrad (%): | 95,0 |
| Nominalspannung Batterie (V): | 24 |
| Schutzart (IP): | 20 |
| Schwebeladung (V): | 27,2 |
| Umschaltzeit (ms): | < 40 |
